• Body-color front & rear fascias
• Rear spoiler
• Front door sill scuff pads
• Body-color grille
• Quad halogen headlamps
• Manual remote control mirrors
• Solar control glass
• Variable intermittent windshield wipers
• Rear window wiper/washer
• Bright door handles
• Deluxe insulation group

• Cloth low-back front bucket seats
• 65/35 split fold/tumble/removable rear seat w/outboard head restraints
• Floor console w/covered storage
• Center console w/12V aux pwr outlet
• Floor carpeting-inc: passenger & cargo compartments
• Tilt steering column
• Sentry Key theft deterrent system
• Instrument panel-inc: satin silver bezel, 120 mph speedometer, tachometer
• Trip computer
• Tire pressure monitoring system lamp
• Pwr windows w/front 1-touch down feature
• Speed sensitive pwr door locks
• Keyless entry w/panic alarm, (2) transmitters
• Front & rear climate control outlets
• Rear window defroster
• AM/FM stereo w/CD player-inc: (4) premium speakers
• Fixed long mast antenna
• Analog clock
• Glove box
• Covered sliding visor vanity mirrors
• Front dome lamp
• Cargo lamp
• Color-keyed shift knob

• Advanced multistage front air bags w/occupant classification system
• Supplemental front seat side air bags
• LATCH-ready child seat anchor system
• Rear door child protection locks
• Single low note horn

2.4L DOHC SMPI 16-VALVE I4 ENGINE

• (STD)

• Quick Order Package 28D
• 3.94 Axle Ratio
• 15" x 6" Black Wheels
• Cloth Low-Back Bucket Seats
• AM/FM Compact Disc
• Air Conditioning
• 4 Speakers
• Front Center Armrest w/Storage
• Compass
• Front beverage holders
• Variably intermittent wipers
• Trip computer
• Tilt steering wheel
• Split folding rear seat
• Remote keyless entry
• Rear window wiper
• Rear window defroster
• Power windows
• Power steering
• Passenger vanity mirror
• Passenger door bin
• Panic alarm
• Outside temperature display
• Occupant sensing airbag
• Low tire pressure warning
• Knee airbag
• Front wheel independent suspension
• Front anti-roll bar
• Dual front side impact airbags
• Dual front impact airbags
• Driver vanity mirror
• Driver door bin
• CD player
• Bumpers: body-color
• AM/FM radio
• Tachometer
• Spoiler
• Front Bucket Seats

• Vehicle
• EPA Classification: Subcompact
• Mileage
• EPA Fuel Economy Est - City (MPG): 21
• EPA Fuel Economy Est - Hwy (MPG): 26
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 510
• Maximum Alternator Capacity (amps): 120
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Weight Information
• Base Curb Weight (lbs): 3070
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 1000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 100
• Wt Distributing Hitch - Max Trailer Wt. (lbs): - TBD -
• Wt Distributing Hitch - Max Tongue Wt. (lbs): - TBD -
• Suspension
• Suspension Type - Front: Macpherson Strut
• Suspension Type - Rear: Twist beam
• Suspension Type - Front (Cont.): w/Coil Springs
• Suspension Type - Rear (Cont.): w/Coil Springs
• Shock Absorber Diameter - Front (mm): - TBD -
• Shock Absorber Diameter - Rear (mm): - TBD -
• Stabilizer Bar Diameter - Front (in): - TBD -
• Brakes
• Brake Type: Pwr
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 11 x 0.9
• Drum - Rear (Yes or ): Yes
• Rear Drum Diam x Width (in): 8.97 x 1.57
• Tires
• Front Tire Order Code: TNC
• Rear Tire Order Code: TNC
• Spare Tire Order Code: TBC
• Front Tire Size: P195/65R15
• Rear Tire Size: P195/65R15
• Spare Tire Size: Compact
• Wheels
• Front Wheel Size (in): 15 x 6.0
• Rear Wheel Size (in): 15 x 6.0
• Spare Wheel Size (in): - TBD -
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: - TBD -
• Steering
• Steering Type: Pwr Rack & Pinion
• Steering Ratio (:1), Overall: 18.1
• Lock to Lock Turns (Steering): - TBD -
• Turning Diameter - Curb to Curb (ft): 36.7
• Turning Diameter - Wall to Wall (ft): - TBD -
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 15.0
• Exterior Dimensions
• Wheelbase (in): 103.0
• Length, Overall (in): 168.9
• Width, Max w/o mirrors (in): 67.1
• Height, Overall (in): 63.0
• Track Width, Front (in): 58.3
• Track Width, Rear (in): 58.2
• Min Ground Clearance (in): 5.5
• Rear Door Opening Height (in): - TBD -
• Rear Door Opening Width (in): - TBD -
• Liftover Height (in): - TBD -
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Seat 1 (in): - TBD -
• Cargo Area Length @ Floor to Seat 2 (in): - TBD -
• Cargo Area Length @ Floor to Seat 3 (in): - TBD -
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): - TBD -
• Cargo Box (Area) Height (in): - TBD -
• Cargo Volume to Seat 1 (ft³): - TBD -
• Cargo Volume to Seat 2 (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 5
• Passenger Volume (ft³): 98.8
• Front Head Room (in): 39.2
• Front Leg Room (in): 40.6
• Front Shoulder Room (in): 53.8
• Front Hip Room (in): 49.6
• Second Head Room (in): 39.5
• Second Leg Room (in): 40.9
• Second Shoulder Room (in): 53.6
• Second Hip Room (in): 41.1
• Summary
• Vehicle Name: Chrysler PT Cruiser
• Body Style: Small Station Wagon
